UMT-2Di Multi-Button MIDI Control Interface

The Nemesis UMT-2Di is a perfect standalone solution for the complex external connectivity requirements of theatrical control and playback software, including QLab, CSC, SFX, SCS, Ableton Live and similar packages.

​

By centralising all external inputs and converting them to standard MIDI commands, the UMT-2Di makes interfacing to a single piece of software quick and easy and can simplify all programming and playback requirements.

​

Manufactured in a rugged hard-wearing box, the UMT-2Di features two large integrated buttons and a high quality rotary encoder for easy access to standard Go, Stop, Previous and Next commands for a complete "all in one" solution.



The UMT-2Di communicates with the host computer using MIDI via the integrated USB interface. In addition, the UMT-2Di provides connectors for optional external GPI signals, such as additional remote operator GO and STOP button pushes or MD triggers.

UMT-2Di Top.png
UMT-2D:i Front.png
UMT-2D:i Back.png

Key features:

  • 2 large software-mappable control buttons

  • Integrated high quality stepped rotary encoder

  • 2 × 3-Pin XLR over-voltage protected inputs for external push button triggering, e.g. MD Start/Stop via an analogue stage multicore link

  • 9-Pin D-SUB connection to facilitate button panels or trigger boxes, e.g. Nemesis REM5D, REM8D

  • Class-compliant integrated USB MIDI Interface, PC and Mac compatible

  • External MIDI interface via breakout providing physical MIDI IN and 2 MIDI OUTs

  • Activity LEDs for button status and enumeration information

  • USB Bus Powered

  • Standalone Mode to allow use as a MIDI generator

  • Internally selectable Program Change/Note On Messages

  • Compatible with Windows XP, Vista, Windows 7 > Windows 10

  • Compatible with Mac OSX Mojave, Catalina and Big Sur (Intel chip variants only)
